Pickup location to confirm
10 × V4DCFC-100SUB
V4 DC fast media chassis. New, factory-crated.
10 unitsV4Factory-crated
VOLTA V4 / DC FAST-CHARGING STATION CHASSIS
129 DC faststation chassis.
The station housing that turns a BTC Power dispenser module and power cabinet into a working DC fast charger. Three part numbers, media and non-media, new and factory-crated.
V4DCFC-100SUB · V4DCFC-103NM · V4DCFC-103SUB-2209129units available
Newfactory-crated, indoor storage
Request quoteYour quantity · confirmed configuration
Lead line: 65 × V4DCFC-103NM. Request a quote for your quantity.
01 / THE INVENTORY
Every part number.
Request your quote.
Compare quantities and generations, then open the part number for specifications and a quote request.
| Part number | Gen. | Units | Location | Quote |
|---|---|---|---|---|
| V4DCFC-100SUB V4 DC fast media chassis | V4 | 10 | Pickup location to confirm | Request quote |
| V4DCFC-103NM V4.3 DC fast chassis, no display | V4.3 | 65 | Pickup location to confirm | Request quote |
| V4DCFC-103SUB-2209 V4.3 DC fast media chassis | V4.3 | 54 | Pickup location to confirm | Request quote |
Every Volta quantity is quote-only. Confirm the exact units, display allocation, pickup location and commercial terms before purchase.
02 / OPEN A PART NUMBER
Pick the line.
Get the detail.
Pickup location to confirm
65 × V4DCFC-103NM
V4.3 DC fast chassis, no display. New, factory-crated.
65 unitsV4.3No display
Pickup location to confirm
54 × V4DCFC-103SUB-2209
V4.3 DC fast media chassis. New, factory-crated.
54 unitsV4.3Factory-crated
03 / HOW A STATION GOES TOGETHER
Cabinet, module, chassis.
All three are here.
No count of complete stations is claimed. Your combination is built from serial records, and the inquiry form captures what you already own.
Power cabinetBTC Power HPCT2 / HPCT
Converts site AC to DC. 50 kW to 360 kW. Feeds one or two stations.
Dispenser moduleBTC Power HPCD5-200 / HPCD5-125
The cable, connector and metering. Mounts inside the chassis.
Station chassisVolta V4DCFC
The housing the driver sees, with or without the media display. This page.
Gen4 pairing
HPCT2-180 or HPCT2-360 cabinet, HPCD5-200 module (190 kW, 200 A), and a compatible chassis from this page. Chassis fit is confirmed by serial records. One Gen4 cabinet can feed two stations.
Gen2 pairing
HPCT-100 or HPCT-50 cabinet, HPCD5-125 module (50 kW, 125 A), and a compatible chassis from this page. Chassis fit is confirmed by serial records. The installed-base replacement path.
Confirmed by serial
Chassis opening, harness, controller, firmware and cabinet interface are checked against the serial records of the exact units before purchase.
04 / INSPECTION + DOCUMENTS
See the stock.
Qualify the configuration.
Start with the crate identification, then review the units allocated to your order and their technical files.
Model + serial
Confirm the part number and the units allocated to your order.
Technical files
Review electrical rating, connector, listings and control or display requirements.
Inspection + quote
Agree on quantity, pickup location and commercial terms once the equipment fits your project.
BUYER QUESTIONS
The questions that matter.
What is a chassis and why would I buy one?
The chassis is the station housing. The BTC Power HPCD5 dispenser modules in this inventory cannot be installed on their own; they mount inside a chassis like these. An operator with a damaged housing, or a buyer assembling stations from modules and cabinets, needs this part.
Media or non-media?
Two of the three part numbers are the media-display housings, with display inclusion and fitment to be confirmed from serial records; the V4DCFC-103NM does not take a display. Confirm the exact housing and controls before purchase. The media housings suit operators who run on-site advertising or driver messaging.
How do I get a quote?
Request a quote for your quantity, part number and destination. Volta pricing is supplied privately for every order size. Configuration, allocation, pickup location and commercial terms are confirmed with the quote.
Where are they?
The chassis are stored indoors. Pickup location and the exact units allocated to your order are confirmed with the quote. Inspection is by appointment.
YOUR PROJECT
Get the records.
Get the right quote.
Tell us the part number, the quantity and where the equipment is going. We confirm the configuration with you before purchase.
DC fast chassis inquiry
Your request is for the Volta V4 chassis lines.
3 part numbers129 units · quote on requestPickup location to confirm
Every inquiry goes to our team the same day.
